Zincalume Steel Coil and Sheet
Zinc / Aluminum alloy-coated steel or Zincalume® steel is composed of 55% aluminium, 43.5% zinc and 1.5% silicon which provides a superior coating for steel, as well as better corrosion resistance.
As aluminium in the coating provides barrier protection to the steel whilst the zinc component provides sacrificial cut edge protection. Therefore, This double protection mechanism is the secret behind Zincalume steel’s superior corrosion performance.
Comparative coating loss of galvanized and Zincalume steel at sites ranging from rural to severe marine.
Extensive research has proven that Zincalume performed the desired non-corrosive functions far better than Galvanized steel. Actual field testing after 20 years has also shown that the roof made from Zincalume steel is still in good condition, while the roof made from galvanized steel shows significant red rust.
ZINCALUME steel has been used with striking effect by leading architects to create the latest in modern building designs, through to classic roofing styles and rural sheds.
Unique aluminium/ zinc/ magnesium alloy coating which acts in three ways:
1. Magnesium, aluminium and zinc compounds are strategically positioned in the coating to provide sacrificial protection
2. Magnesium compounds encourage the formation of a robust barrier, slowing the rate of subsequent corrosion
3. Magnesium compounds also activates the metal coating.
Australian and New Zealand Standard: AS/NZS 1365;AS/NZS 1397:2010
Specification: G1~G3, G250~G550
Base Steel Thickness: 0.27~2.45mm
Width: 20mm~1550mm Length: Up to 12,000mm
Coating Mass: ZA90~ZA450
Surface Finish: Regular Spangle/Minimised Spangle/Zero Spangle
Surface Treatment: Chromating treatment, Oiled or Resin Coated (Anti-Fingerprint)
Benefits:
- Easy to paint
- Extraordinary mark resistance
- Special benefits for the roll former
- A Joint effort
- Welding is easy
- Fastening is a strong point
- Compatibility and best of all
Application:
- roofing and flashing
- wall cladding
- gutters and down-pipes
- fences
- steel house frames
- garage doors
- garden sheds
- some vehicle exhaust components
- flues
